vacon • 12 Receipt of delivery
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
3.2 Type designation code for the LCL filter
LCL filters has two versions of cooling fan power supply, one without the integrated DC/DC power
supply and one with it. The LCL filter is characterized without the integrated DC/DC power supply
by letter A and with the integrated DC/DC power supply by letter B in version column, Table 4.
A1 A2 00 00 00
Option boards; each slot is represented by two characters:
00 = the slot is not used
A = Basic I/O board B = Expander I/O board
C = Fieldbus board D = Special board E = Fieldbus board
Table 4.
Type designation code for the LCL filters
Code Description
LCL
Product range
LCL = LCL filter for AFE
AAAA
Nominal current (low overload)
E.g. 0261 = 261 A,0460 = 460 A and so on.
V
Voltage class
5 = 380-500 VAC
6 = 525-690 VAC
A
Version (hardware)
A = DC fan without DC/DC power supply
B = DC fan with integrated DC/DC power supply
0
Enclosure class:
0 = IP00
R Reserve
0 Reserve
1 Reserve
1
Cooling fan type
1 = DC fan
T
Manufacturer
T = Trafotek
Table 3. Type designation code for the VACON® Active Front End
Code Description

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
