Control Keypad vacon • 87
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
6
6.3 Navigation on the control keypad
The data on the control keypad is arranged in menus and submenus. The menus are used for the
display and editing of measurement and control signals, parameter settings (see Chapter 6.3.2) and
reference value and fault displays (see Chapter 6.3.4). Through the menus, you can also adjust the
contrast of the display (see Chapter 6.3.8.5).
The first menu level consists of menus M1 to M7 and is called the Main menu. The user can navigate
in the Main menu with the Browser buttons up and down. The desired submenu can be entered from
the Main menu with the Menu buttons. When there still are pages to enter under the currently
displayed menu or page, you can see an arrow ( ) in the lower right corner of the display and can
reach the next menu level by pressing Menu button right.
The control keypad navigation chart is shown on the next page. Note that menu M1 is located in the
lower left corner. From there you will be able to navigate your way up to the desired menu using the
menu and browser buttons.
You will find more detailed descriptions of the menus later in this chapter.
Location
n
Number of items
available
V1
V14
READY
Local
RUN
Monitor
11206.emf
To Next Page
