vacon • 16 Receipt of delivery
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
3.6 Lifting the modules
The modules can be lifted by the holes on top. Place the lifting hooks symmetrically in at least four
holes. The maximum allowed lifting angle is 45º. For enclosure sizes FI9 and FI10, see Figure 1 and
for the enclosure size FI13, see Figure 2.
The lifting equipment must be able to carry the weight of the module.
Figure 1. Lifting points for FI9 and FI10 modules
45
11179.emf

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
