4.13 Main contactor
If a main contactor is to be used, the types shown in Table 25 are recommended. If a contactor from
another manufacturer is used, it must be equivalent to the types shown. Further information on the
contactors shown is available from the manufacturer.
Table 25. Recommended main contactor types
Type FI9 Contactor / 500 V
FI9 A210-30-11-80 Contactor, 350 A/690 V, AC3 110 KW/400 V, 230 VAC-Coil
Type FI9 Contactor / 690 V
FI9 A185-30-11-80 Contactor, 275 A/690 V, AC3 132 KW/690V, 230 VAC-Coil
Type
FI10 Contactor / 500 V
FI10
AF400-30-11-70 Contactor, 600 A/500 V, AC3 200KW/400V, 100…250 V AC/DC coil
Type
FI10 Contactor / 690 V
FI10
AF300-30-11-70 Contactor, 500 A/690 V, AC3 250 KW/690 V, 100…250 V AC/DC coil
Type FI13 Contactor / 500 V
FI13 AF1650-30-11-70 Contactor, 1650 A/500 V, AC3 560 KW/400 V, 100…250 V AC/DC coil
Type FI13 Contactor / 690 V
FI13 AF1350-30-11-70 Contactor, 1350 A/690 V, AC3 --- KW/400 V, 100…250 V AC/DC coil

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
