Vacon NX series User Manual

4
vacon • 38 Active Front End (AFE)
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
4.9 Active Front End unit – Dimensions
NOTE! More detailed dimensions can be found Appendix 77, Appendix 78 and Appendix 79.
4.10 LCL filter – Dimensions
NOTE! Weight is different for 500 V/690 V other dimensions are same for both voltage classes.
NOTE! More detailed dimensions can be found Appendix 80 and Appendix 81.
Table 11. The NXA unit dimensions
Module Module Dimension
Type
Enclosure
size
Height [mm] Width [mm] Depth [mm] Weight [kg]
AFE
FI9 1030 239 372 67
FI10 1032 239 552 100
FI13 1032 708 553 306
Table 12. LCL filter dimensions
Module Module Dimension
Type
Enclosure
size
Height [mm] Width [mm] Depth [mm] Weight [kg]
LCL
FI9 1775 291 515 241/245
FI10 1775 291 515 263/304
FI13 1442 494 525 477/473

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
