Vacon NX series User Manual

6
vacon • 86 Control Keypad
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
6.2.1 Buttons descriptions
= This button is used to reset active faults. See Chapter 6.3.4.
=
This button is used to switch between the two latest displays. This may be useful
when you want to see how the changed new value influences some other value.
=
The enter button is used for:
1) confirmation of selections.
2) fault history reset (2…3 seconds).
=
Browser button up.
Browse the main menu and the pages of different submenus.
Edit values.
=
Browser button down.
Browse the main menu and the pages of different submenus.
Edit values.
=
Menu button left
Move backward in menu.
Move cursor left (in parameter menu).
Exit edit mode.
=
Menu button right
Move forward in menu.
Move cursor right (in parameter menu).
Enter edit mode.
=
Start button
Pressing this button starts VACON
®
NX Active Front End (modulation) if the key-
pad is the active control place. See Chapter 6.3.3.
=
Stop button
Pressing this button stops VACON
®
NX Active Front End (unless disabled by
parameter R3.4/R3.6). See Chapter 6.3.3.
reset
select
enter
+
-



Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
