vacon • 44 Active Front End (AFE)
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
4.12 Active Front End unit – Circuit breaker selection
The Active Front End can also be protected by a circuit-breaker. The recommended types of circuit-
breakers are shown in Table 24. If a circuit-breaker from another manufacturer is used, it must be
equivalent to the circuit-breakers shown. Further information on the circuit-breakers shown is
available from the manufacturer. Circuit-breakers do not provide same level of protection as fuses,
therefore, fuses are always recommended to be used. A circuit-breaker can be used without a main
contactor. In this case, the Active Front End unit controls the circuit-breaker instead of the
contactor. The circuit-breakers shown are suitable for equipment rated at 380 V–500 V or 525 V–690
V.
Table 24. Circuit breaker for VACON
®
NXA
Type T5H400FF3LS
FI9
T5H400FF3LS
MOE230V/T4-5
UVRC230V/T4-5
ES-6/T5
AUX-C3+1/T4-5
PB100/T4-5-3P
AUX-SA1-S51+1/T4-5
MCCB
Motor
Undervoltage rel. (cabled)
Spreaded ext. term. incl. PB100
Aux./alarm cont. (cabled)
Phase separators for upper/lower
terminals
S51 NC
1SDA054349R1
1SDA054897R1
1SDA054891R1
1SDA055038R1
1SDA054911R1
1SDA054970R1
1SDA064518R1
Type T5H630FF3LS
FI10
T5H630FF3LS
MOE230V/T4-5
UVRC230V/T4-5
ES-6/T5
AUX-C3+1/T4-5
PB100/T4-5-3P
AUX-SA1-S51+1/T4-5
MCCB
Motor
Undervoltage rel. (cabled)
Spreaded ext. term. incl. PB100
Aux./alarm cont. (cabled)
Phase separators for upper/lower
terminals
S51 NC
1SDA054412R1
1SDA054897R1
1SDA054891R1
1SDA055038R1
1SDA054911R1
1SDA054970R1
1SDA064518R1
Type T7S16FF3PR231LS
FI13
E1.2N 1600A Ekip Dip LI 3p F-F
M E1.2 220-250Vac/dc
YR 250Vac/dc E1.2
RTC 250V E1.2
YO E1.2 220-240Vac/dc
YC E1.2 220-240Vac/dc
YU E1.2 220-240Vac/dc
PB Separators H=200mm 4pz
E1.2 F 3P
Spring charging Motor
Reset coil
Ready to close auxiliary contact
Opening coil
Closing coil
Undervoltage coil
Phase separators
1SDA070881R1
1SDA073711R1
1SDA073746R1
1SDA073770R1
1SDA073674R1
1SDA073687R1
1SDA073700R1
1SDA073879R1

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
