Active Front End (AFE) vacon • 27
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
4
Storage temperature -40 °C (-104 °F)...+70 °C (158 °F)
Relative humidity
0 to 95% RH, non-condensing, non-corrosive, no
dripping water.
Air quality:
- chemical fumes
-solid particles
Designed according to
• IEC 60721-3-3, AC drive in operation, class 3C2
• IEC 60721-3-3, AC drive in operation, class 3S2
Elevation of place of
operation
100% loadability (no derating) up to 1000 m.
Maximum elevation 2000 m (525-690 VAC) and
4000 m (380-500 VAC),
Relay I/O: max. 240 V: 3000 m; max. 120 V: 4000 m,
see Power derating as a function of installation
altitude. See Chapter 4.16.
Vibration
IEC/EN 61800-5-1/
EN 60068-2-6
5…150 Hz.
FI9:
• Vibration amplitude 1 mm (peak) in
frequency range 5…15.8 Hz.
• Max. acceleration 1 G in frequency range
15.8…150 Hz.
FI10-13:
• Vibration amplitude 0.25 mm (peak) in
frequency range 5…31Hz.
• Max. acceleration 1 G in frequency range
31…150 Hz.
Impacts
EN 50178,
EN 60068-2-27
UPS drop test (with applicable UPS weights)
Storage and transport: max. 15 G, 11 ms (packed).
Enclosure class IP00/Open type standard size in the kW/HP range.
EMC (using factory
settings)
Immunity
IEC/EN 61800-3:2004+A1:2012, second
environment
Noise level
Average noise level
(cooling fan) in dB(A)
FI9: 76
FI10: 76
FI13: 81
Safety standards
IEC/EN 61800-5-1, UL 508C, CSA C22.2 No.274
T-level, see chapter 2.2.3.
Approvals
CE, cULus, RCM, KC, EAC, UA. (See the nameplate
of the drive for more approvals.)
Marine approvals: LR, BV, DNV, GL, ABS, RMRS,
CCS,KR.
Table 7. Technical specification for VACON
®
NXA Active Front End unit
