Active Front End (AFE) vacon • 41
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
4
NOTE! All fuses are flush-end type. If some other type is needed, contact your distributor.
NOTE! Fuses for FI9 is fuse links type and for FI10 and FI13 are flush-end type. If some other type is needed,
contact your distributor.
Table 17. Bussman DC fuse selection, mains voltage 465–800 Vdc
Module DC fuses
Type Code
Enclosure
size
Bussman
type [aR]*
U
N
[V]
I
N
[A]
Size Q'ty
AFE
NXA_0168 5 FI9 170M6458 690 500 3BKN/50 2
NXA_0205 5 FI9 170M6458 690 500 3BKN/50 2
NXA_0261 5 FI9 170M6462 690 800 3BKN/50 2
NXA_0385 5 FI10 170M6466 690 1250 3BKN/50 2
NXA_0460 5 FI10 170M6466 690 1250 3BKN/50 2
NXA_1150 5 FI13 170M7084 690 3000 4BKN/65 2
NXA_1300 5 FI13 170M7084 690 3000 4BKN/65 2
Table 18. Bussman DC fuse selection, mains voltage 465–800 Vdc, North-America
Module DC fuses
Type Code
Enclosure
size
Bussman
type [aR]*
U
N
[V]
I
N
[A]
Size Q'ty
AFE
NXA_0168 5 FI9 170M1777 800 400 FU/70 2
NXA_0205 5 FI9 170M1777 800 400 FU/70 2
NXA_0261 5 FI9 170M1781 800 630 FU/70 2
NXA_0385 5 FI10 170M6499 1200 1100 3BKN/90 2
NXA_0460 5 FI10 170M6499 1200 1100 3BKN/90 2
NXA_1150 5 FI13 170M6499 1200 1100 3BKN/90 3x2
NXA_1300 5 FI13 170M6499 1200 1100 3BKN/90 3x2

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
