vacon • 68 Installation
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Figure 39. Cabinet cooling airflow guides for FI9 and FI10 AFE unit and LCL filter
Figure 40. Cabinet cooling airflow guides for FI13 AFE unit and LCL filter
Sheet
metal
Shield
Shield
Front
Shield
Front
Shield
Shield
Back
Sheet metal
