Vacon NX series User Manual

Control Keypad vacon • 97
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
6
S6.3.3 Down from keypad
All parameters
All but motor parameters
Application parameters
P6.3.4 Autom. BackUp Yes
No
Yes
S6.4 Parameter comparison
S6.5 Security
S6.5.1 Password Not used 0 = Not used
P6.5.2 Parameter locking
Change
Enabled
Change Enabled
Change Disabled
S6.5.3 Start-up wizard
No
Yes
S6.5.4 Multimonitoring items
Change
Enabled
Change Enabled
Change Disabled
P6.5.5 OPTAF Remove
S6.6 Keypad settings
P6.6.1 Default page
P6.6.2 Default page/OM
P6.6.3 Timeout time 0 65535 s 30
P6.6.4 Contrast 0 31 18
P6.6.5 Backlight time Always 65535 min 10
S6.7 Hardware settings
P6.7.1
Internal brake
resistor
Connected
Not connected
Connected
P6.7.2 Fan control function Continuous
Continuous
Temperature
First Start
Calc temp
P6.7.3 HMI acknowledgment 200 5000 ms 200
P6.7.4 HMI: no. of retries 1 10 5
P2.6.7.5 Sine Filter
Not connected
Connected
P2.7.6 Pre-Charge Mode
Normal FC
Ext. ChSwitch
S6.8 System information
S6.8.1 Total counters
T6.8.1.1. MWh counter kWh
T6.8.1.2. PwOn Day Counter
T6.8.1.3. PwOn Hour Count.
S6.8.2 Trip counters
T6.8.2.1 MWh counter
T6.8.2.2 Clr MWh Counter
Not Reset
Reset
Table 36. System menu functions
Code Function Min Max Unit Default Selections

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
