Vaisala HMP3 - Canada ICES-003 Compliance Statement

To Next Page

To Previous Page

Changes or modiﬁcations to this equipment not expressly approved

by the party responsible for compliance could void the user's authority to

operate the equipment.

CAUTION!

2.7.2 Canada ICES-003 compliance statement

This Class B digital apparatus complies with Canadian ICES‑003.

Cet appareil numerique de la classe B est conforme a la norme NMB‑003 du Canada.

Chapter 2 – Product overview
