Vaisala HMP3 - Table 8 Inputs and Outputs; Table 9 Mechanical Specifications

96 pages

Save Page as PDF

To Next Page

To Previous Page

Table 8 Inputs and outputs

Property Description/value

Operating voltage 15 … 30 VDC

Current consumption 10 mA typical, 500 mA max.

Digital output RS-485, non-isolated

Protocols Modbus RTU

Output parameters

Relative humidity, temperature, dew point temperature, dew point temperature dierence (T−T

d/f

wet-bulb temperature, absolute humidity, mixing ratio, water concentration, water vapor pressure,

enthalpy

Table 9 Mechanical speciﬁcations

Property Description/value

Connector M12 5-pin A-coded male

Weight 302 g (10.65 oz)

Materials

Probe AISI316L

Probe body AISI316L

Cable jacket FEP

Chapter 8 – Technical data
