Vaisala HMP3 - Figure 42 MMP8 Dimensions; Table 33 Mechanical Specifications

Property Description/value
Protocols Modbus RTU
Output parameters
Temperature, water activity, relative saturation, water mass fraction (ppm)
Table 33 Mechanical Specifications
Property Description/value
Connector M12 5-pin A-coded male
Weight 510 g (18.0 oz)
Filter options Stainless steel grid standard filter
Stainless steel grid filter for high flow rates (> 1
m/s)
Probe cable length 2 m (6.56 ft)
Adjustable installation depth 35 … 179 mm (1.37 … 7.05 in)
Materials
Probe AISI316L
Probe body AISI316L
Cable jacket FEP
136 [5.35]
Probe cable 2 m [6.56 ft]
Ø 25
[0.98]
M12/5
Ø 5
[0.2]
mm
[in]
262 [10.32]
224 [8.82]
35 ... 179 [1.37 ... 7.05]
35 [1.37]
Ø 13.5
[0.53]
Fitting body
ISO1/2” or NPT1/2”
Ø 12
[0.47]
Figure 42 MMP8 dimensions
Chapter 8 – Technical data
69
