136 [5.35]
Probe cable 2 m [6.56 ft]
Ø 25
[0.98]
M12/5
183 [7.20]
120 [4.72]
41 [1.61]
Ø 5
[0.2]
Fitting body NPT1/2” or M22×1.5
with sealing ring Ø22×27×1.5 Cu
Ø 12
[0.47]
32 mm 27 mm
mm
[in]
Figure 29 HMP4 probe dimensions
8.3
HMP5 specifications
Table 14 Measurement performance
Property Description/value
Relative humidity
Measurement range 0 … 100 %RH
Accuracy at +23 °C (+73.4 °F)
1)
±0.8 %RH (0 … 90 %RH)
Factory calibration uncertainty
2)
±0.5 %RH (0 … 40 %RH)
±0.8 %RH (40 … 95 %RH)
T
63
response time 15 s
Sensor options HUMICAPâ R2
HUMICAPâ R2C
3)
Temperature
Measurement range −70 … +180 °C (−94 … +356 °F)
Accuracy at +23 °C (+73.4 °F)
1)
4)
±0.1 °C (±0.18 °F)
Chapter 8 – Technical data
55
