Vaisala HMP3 - Figure 18 HMP7 Attached to Indigo 200 Series Transmitter with a Cable

1
2
3
Figure 18 HMP7 attached to Indigo 200 series transmitter with a cable
1
Cable to probe head
2 Locking wheel: insert cable, hold in place, and turn the wheel counterclockwise
3 Connection cable
The probe can be connected to Vaisala Indigo transmitters, either directly on the transmitter
from the probe's connector, or by using a cable between Indigo and the probe.
Indigo transmitters are host devices that extend the feature set of connected probes with a
range of additional options for outputs, configuration access, measurement viewing, and
status monitoring.
The selection of available additional features (for example, output and connectivity options)
varies depending on the Indigo transmitter model. Depending on the model, a display is
available as an optional selection or as a standard feature. In the non-display model, an LED
indicator is used for notifications.
HMP3, HMP4, HMP5, HMP7, HMP8, HMP9, MMP8, TMP1 User Guide M212022EN-D
32
