5. Using probe with Indigo transmitters

5.1 Indigo 200 series transmitter overview

Figure 17 HMP7 attached to Indigo 200 series transmitter

3.5” TFT LCD color display: non-display option with LED available for certain models

2 Locking wheel: insert probe, hold in place, and turn the wheel counterclockwise

3 Cable to probe head

4 Wireless conﬁguration interface (WLAN) activation button

5 Rubber lead-through with strain relief. Cable feedthrough option also at back of

transmitter.

6 Input/output cable

Chapter 5 – Using probe with Indigo transmitters
