136 [5.35]

Probe cable 2 m [6.56 ft]

Ø 25

[0.98]

M12/5

Ø 12

[0.47]

41 [1.61]

Ø 13.5

[0.53]

Fitting body

ISO1/2” or NPT1/2”

Ø 5

[0.2]

[in]

268 [10.55]

230 [9.06]

41 ... 185 [1.16 ... 7.28]

Figure 38 HMP8 probe dimensions

Ø 21.5 [0.83]

(drilling)

Ø 14 [0.55]

195 [7.67]

ISO1/2” ﬁtting body

supplied with HMP8

ISO1/2”

80 [3.15]

[in]

Figure 39 Optional ball valve installation kit dimensions

8.6

HMP9 speciﬁcations

Table 26 Measurement performance

Property Description/value

Relative humidity

Measurement range 0 … 100 %RH

HMP3, HMP4, HMP5, HMP7, HMP8, HMP9, MMP8, TMP1 User Guide M212022EN-D
