9. Technical Data
9.1 Specifications
Table 6 Inputs and Outputs
Property Specification
Analog outputs 3 voltage (V) or current (mA) outputs:
• 0 … 10 V / 0 … 5 V / 0 … 1 V / 1 … 5 V (min. load
1kΩ)
• 0 … 20 mA / 4 … 20 mA (max. load 500 Ω)
Accuracy of analog outputs at 20 °C ± 0.1 % full scale
Relays 2 configurable relays (VAC/VDC)
Device maximum specification (resistive load):
• Max. switching power 30 W / 37.5 VA
UL-rated maximum specification (resistive load):
• AC: max. 28 V / 0.5 A
• DC: max. 40 V / 0.24 A
• Up to 30 VDC:
• max. switching current 1 A
• max. switching power 30 W
Power supply input
1)
Range 15 ... 30 VDC (20 ... 22 VAC)
Maximum current Transmitter and connected probe max. 1 A
Power consumption Transmitter max. 3 W (+ connected probe, varies
depending on probe type)
Probe connector M12/5 connector for probe or probe cable connection
(Vaisala Indigo-compatible probes)
Cable feed throughs 2 options: rubber lead-through on the bottom of the
transmitter, and opening with a seal at the back of the
transmitter
Screw terminal wire size
0.2 ... 1.5 mm
2
1) Using a power supply with overload protection is recommended for electrical safety.
Table 7 General
Display (optional) 3.5” TFT LCD color display
Configuration interface Browser-based wireless configuration interface (IEEE
802.11 b/g/n WLAN)
Chapter 9 – Technical Data
71
