9.3 Dimensions (in mm)
135 mm
149 mm
135 mm
43 mm
Probe-specific
50 mm
2.5 mm
Ø 4.0 mm
114 mm
101 mm
25 mm
Ø 4.5 mm
13
Secondary mounting option with 4 screws:
designed for Würth 4.0×1.8 mm Plastofast
(self-tapping screws for plastics).
Hole depth 12 mm.
37 mm
4.5 mm
Figure 34 Indigo Transmitter Dimensions in Millimeters (mm)
