43
Installation With 1430FFK—Fixed Framing Kit
6. Install the upper panel as indicated (3 screws).
7. Slide the appliance into the framing and secure it to
the studs on each side (6 fi xing points per side).
8. Set aside the side doors, removable panel and bar-
rier screen to install later when the appliance’s set-
up and wall fi nish application are completed
9. Continue the installation of the heater as indicated
in this manual.
