Appendix E - Spare Parts
Description
Part
Number
41 Valve mount 4003956
42
GV60 valve assembly (natural gas) 4009150X
GV60 valve assembly (propane gas) 4009151X
43 Thermocurrent interrupter 4001037
44 Pipe s/s fl ex ACS-375MM-12 4000345
45 Block/pipe connector 4006689
46 Gas pipe 4006993
47 Single pipe sealing plate 4006982
48 Module plate 4007747
49 Gasket module plate, rear 4003925
50 Gaskets module plate, RH 4003926
51 Gasket module plate, front 4003924
52 Gaskets module plate, LH 4003927
53 Burner mounting bracket, LS 4007538
54 Burner mounting bracket, RS 4007537
55 Receiver Valor 10 two-way 4005597
56 Wire harness GV60 4001187
57 Yellow cable to interruptor 4002096
58
Red cable to interruptor
4001035
59 V-Module - Relay box 4002530
60 12” Power cord w/Molex 4004493
61 Cable, v-module to receiver 4008199
62 Valor 10-button handset, black 4007548
63 Valor 10 handset wall holder 4004459
64 GV60 Valve Repair Kit (not included) 4004544
65 Remote battery & Wall switch kit RBWSK
aJunction box 4005527
b Cover plate & 4 screws 4005526
c Battery holder BH-343-3B6 4006553
dCable tie 4005524
eHarness assembly 4005523
fPlate with magnets 4005391
g Long screws (4) 4001444
h Wall switch with 2 screws 4005522
i Battery cover assembly 4006553
66 G6.35 35W halogen bulb (2) 4009220
67 Liner panels - complete sets
Valor Red Brick Liners 1410VRL
Ledgestone Liner Set 1415LSLV2
Fluted Black Liner Set 1425FBL
Plain Black Liner Set 1460PBL
Glass Liner Set 1470RGL
Clipping brackets (4) 4004981
Herringbone Liners 1475HBL
Description
Part
Number
1 Heat shield, stand-off s4009109
2 Heat shield, vent 4004512
3 45 degrees fl anged elbow 0945JM
4 Elbow gasket 4002999
5Top stand-off s (2) 4009110
6 Restrictor plates (2) 4001222
7Cover plates (4) 4005409
8 Engine positioning brackets (2) 4005225
9 LH Convection gap bracket 4007437
10 RH Convection gap bracket 4007436
11 Brackets, for trim (4) 4008935
12 Frame fi xing brackets (2) 4005226
13 Window latch assembly (4) 4008901
14 Window latches pull handle 4009219
16 Liner panel anchors (2) 4001283
17 Removable convection baffl e, for HeatShift 4005680
18 Electrical Housing 4004450
19 Snap-in receptacle 3-prong 4004495
20 H5 Steel burner assembly 4007401AH
21 Burner cover plate 4007746AH
22 Window assembly 4009044
23 Hot glass warning plate 4003093
24 1/2” Micore 300 insulation board 4001489
25
Module plate assembly (natural gas) 4008190
Module plate assembly (propane gas) 4008191
26 Pilot shield 4008836AH
27 Pilot gaskets (2) 4000715
28
PSE Pilot assembly 36” (natural gas) 4008484
PSE Pilot assembly 36” (propane gas) 4008485
29 Thermocouple 4008490
30
Pilot injector #BL22N (natural gas) 4008493
Pilot injector #BL14LP (propane gas) 4008494
31 Pilot stand 4007751
32 Air shutter stopper 4009073
33 1/8” NPT brass socket head pipe plug 4008003
34 Orifi ce/aeration block 4007702
35
Gas orifi ce #32 (natural gas) 4007000-32
Gas orifi ce #49 (propane gas) 4007000-49
36 Air shutter 4009157
37 Aeration lever 4009071
38 #10 x 1/2” fl at washers (2) 4006692
39 3/16” x 9/16” spring washers (2) 4006691
40 #10-24 zinc fi nish steel reverse nuts (2) 4007890
