Approved Venting Components
Venting Parts
Description
Venting Parts Code / availability by Manufacturer
DURA-VENT
SELKIRK
ICC EXCEL
DIRECT
SECURE
VENT
RLH
INDUSTRIES
AMERIVENT
MILES
INDUSTRIES
BDM
Pipes 4” x 6 5/8” ( ID x OD )
6” long
Galvanized 46DVA-06 4DT-06 TC-4DL6 SV4L6
— — —
94610606
Black 46DVA-06B 4DT-06(B) TC-4DL6B SV4LB6 90410606B
7” long
Galvanized
—————
4D7
——
Black 4D7B
9” long
Galvanized 46DVA-09 4DT-09 TC-4DL9
— — — —
94610609
Black 46DVA-09B 4DT-09(B) TC-4DL9B 94610609B
12” long
Galvanized 46DVA-12 4DT-12 TC-4DL1 SV4L12
—
4D12
—
94610612
Black 46DVA-12B 4DT-12(B) TC-4DL1B SV4LB12 4D12B 94610612B
18” long
Galvanized 46DVA-18 4DT-18
— — — — —
94610618
Black 46DVA-18B 4DT-18(B) 94610618B
24” long
Galvanized 46DVA-24 4DT-24 TC-4DL2 SV4L24
—
4D2
—
94610624
Black 46DVA-24B 4DT-24(B) TC-4DL2B SV4LB24 4D2B 94610624B
36” long
Galvanized 46DVA-36 4DT-36 TC-4DL3 SV4L36
—
4D3
—
94610636
Black 46DVA-36B 4DT-36(B) TC-4DL3B SV4LB36 4D3B 94610636B
48” long
Galvanized 46DVA-48 4DT-48 TC-4DL4 SV4L48
—
4D4
—
94610648
Black 46DVA-48B 4DT-48(B) TC-4DL4B SV4LB48 4D4B 94610648B
Flashings
Roof Flashing
0/12-6/12
46DVA-F6 4DT-AF6 TF-4FA SV4FA —
4DF
(0/12-5/12)
— 949606012
Roof Flashing
7/12-12/12
46DVA-F12 4DT-AF12 TF-4FB SV4B —
4DF12
(6/12-12/12)
— 949606712
Flat Roof Flashing 46DVA-FF — TF-4F SV4F — — — 949606001
Masonry Flashing — — TF-4MF — — — — —
New Siding Flashing — — — — — — 658NSFK —
Various Venting System Parts
Wall Thimble 46DVA-WT 4DT-WT TM-4WT SV4RSM — 4DWT — 949064U
Storm Collar 46DVA-SC 4DT-SC TM-SC SV4AC — 4DSC — 94960608
Decorative Plate 46DVA-DC 4DT-CS
TM-4TR
TM-4TP
SV4PF — 4DFPB — 94940612
Cathedral Ceiling
Support
46DVA-CS 4DT-CCS TM-4SS — — 4DRSB — 949506KT
Ceiling Firestop /
Floor Support
46DVA-FS 4DT-FS
TM-4RDS SV4BF
— 4DFSP — 94980612
TM-CS SV4SD
Attic Radiation Shield /
Firestop
— — TM-4AS — —
4DAIS12 (12”)
— 94930620A
4DAIS36 (36”)
Wall Strap 46DVA-WS 4DTWS TM-WS — — 4DWS — 949164
Vinyl Siding Standoႇ 46DVA-VSS 4DT-VS TM-VSS SV4VS — 4DHVS — 94800615S
Elbow Strap / Oႇ set
Support
46DVA-ES 4DT-OS TM-OS — — — — 949264
Terminal Guard 46DVA-WG —
TM-HTS
—— —
845TG
940164SHRD
TM-RHTS 658TG
Notes: 1. Follow instructions supplied with each manufacturer’s components.
2. Unless otherwise speci¿ ed, all the parts and assemblies from the above table are to be used with 4” x 6-5/8” pipes.
3. Do not mix components from diႇ erent vent manufacturers.
4. Termination caps manufactured by RLH Industries or American Metal Products are from Homestyle Chimney Collection and can be ordered in one of
the following ¿ nishes: a) aluminium; b) black powder coated; c) solid copper.
