Valor H6 - Page 96

96
Appendix D - HeatShift System
!
ɄWARNING
DO NOT INSTALL 1270RBK Remote Blower
Kit to any of these 4 takeo΍ s.
ɄWARNING
All FOUR (4) takeoffs MUST BE
CONNECTED TO PLENUM(S).
Remove Convection Baɞ e
To be e΍ ective the HeatShift Kits require that a
convection baɞ e located above the ȴ rebox inside the
appliance case be removed to allow the hot airȵ ow to
convect upwards into ducts installed on the ȴ replace.
Remove the convection baɞ e from the
appliance. It is held in place by screws located
right behind the upper edge of the ȴ replace
opening (3 screws/baɞ e for 1100’s, 4 for 1400’s
ba΍ ȵ e). Recycle this panel as it is no longer
needed.
Convection
baɞ e to be
removed
Convective
airflow with
baffle removed
Take-of f
collar
Firebox
Re-direction of convected air after removing baɞ e
Convective
airȵ ow with
baɞ e in place
Appliance top panel—shown transparent
for clarity
Remove convection baɞ e
Convection baɞ e
Install HeatShift collars
1. Remove the four cover plates on top of the appli-
ance case (6 screws each).
2. Install the collars on the holes on top of the appli-
ance’s case (6 screws each).
