VAMP Ltd Feeder and motor manager
Operation and configuration
VAMP 257
VM257.EN002 VAMP 24h support phone +358 (0)20 753 3264
11
2.2.4. Indicators
The manager is provided with eight LED indicators:
Power
Error
Com
Alarm
Trip
A
B
C
Figure 2.2.4-1. Operation indicators of the manager
Power Auxiliary voltage switched on
Error
Internal fault, operates in parallel with the self supervision
output relay
Com Serial communication indicator
Alarm The start indicator of the protection stage
Trip The trip indicator of the protection stage
A - C Freely programmable application-related status indications
