2.5. Control functions
2.5.1. Controllable objects
The manager allows controlling of six objects, that is, circuit-
breakers, disconnectors and earthing switches. Controlling can
be done by "select-execute" or "direct control" principle.
The logic functions can be used to configure interlocking checks
for a safe controlling before the output pulse is issued. The
objects 1, 2, 3, 4, 5 and 6 are controllable while the object 7 and
8 are not (for these, only the status is shown).
Controlling is possible by the following ways:
• through a local HMI
• through a remote communication
• through a digital input.
The connection of an object to specific output relays is done via
an output matrix (object 1-6 open output, object 1-6 close
output). There is also an output “Object failed”, which is
activated if the controlling of an object is unsuccessful.
Object parameters (only in VAMPSET software):
Parameter Value Unit Description
Obj1 State Close;
Open;
Undefined(00);
Undefined(11)
Actual state of object 1
Obj2 State Close;
Open;
Undefined(00);
Undefined(11)
Actual state of object 2
Obj3 State Close;
Open;
Undefined(00);
Undefined(11)
Actual state of object 3
Obj4 State Close;
Open;
Undefined(00);
Undefined(11)
Actual state of object 4
Obj5 State Close;
Open;
Undefined(00);
Undefined(11)
Actual state of object 5
States
Obj6 State Close;
Open;
Undefined(00);
Undefined(11)
Actual state of object 6
