Setting parameters of CB wear condition monitoring:
CBWEAR ( )
Parameter Value Unit Default Description
Alarm1 Current 0.00 … 100.00; kA 2.00 kA
Current level for
alarm 1
Alarm1
Cycles
0 … 100000 - 30
Permissible cycle for
alarm 1
Alarm2
Current
0.00 … 100.00 kA 0.63
Current level for
alarm 1
Alarm2
Cycles
0 … 100000 - 200
Permissible cycle for
alarm 1
Clear -; CB1; CB2;
CB3; All
- -
Clear cycle counters
(CB1 = pole L1)
Breaker curve points:
Current1 0.00 … 100.00 kA 0.00
Current value for
curve point 1
Current2 0.00 … 100.00 kA 0.05
Current value for
curve point 2
Current3 0.00 … 100.00 kA 0.30
Current value for
curve point 3
Current4 0.00 … 100.00 kA 0.60
Current value for
curve point 4
Current5 0.00 … 100.00 kA 1.00
Current value for
curve point 5
Current6 0.00 … 100.00 kA 5.00
Current value for
curve point 6
Current7 0.00 … 100.00 kA 10.00
Current value for
curve point 7
Current8 0.00 … 100.00 kA 16.00
Current value for
curve point 8
Cycles1 0 … 100000 - 100000
Cycle value for curve
point 1
Cycles2 0 … 100000 - 15000
Cycle value for curve
point 2
Cycles3 0 … 100000 - 15000
Cycle value for curve
point 3
Cycles4 0 … 100000 - 15000
Cycle value for curve
point 4
Cycles5 0 … 100000 - 5000
Cycle value for curve
point 5
Cycles6 0 … 100000 - 200
Cycle value for curve
point 6
Cycles7 0 … 100000 - 45
Cycle value for curve
point 7
Cycles8 0 … 100000 - 20
Cycle value for curve
point 8
Alarm 1 on event On; Off - On
Alarm 1 off event On; Off - On
Alarm 2 on event On; Off - On
Alarm 2 off event On; Off - On
