VAMP 257 Feeder and motor manager
Operation and configuration
VAMP Ltd
22
VAMP 24h support phone +358 (0)20 753 3264 VM257.EN002
Value Menu/Submenu Description
SL3 P/POWER/PHASE 2 Apparent power of phase 3 [kVA]
PF_L1 P/POWER/PHASE 2 Power factor of phase 1 [ ]
PF_L2 P/POWER/PHASE 2 Power factor of phase 2 [ ]
PF_L3 P/POWER/PHASE 2 Power factor of phase 3 [ ]
cos P/COS & TAN Cosine phi [ ]
tan P/COS & TAN Tangent phi [ ]
cosL1 P/COS & TAN Cosine phi of phase L1 [ ]
cosL2 P/COS & TAN Cosine phi of phase L2 [ ]
cosL3 P/COS & TAN Cosine phi of phase L3 [ ]
Iseq
P/PHASE
SEQUENCIES
Actual current phase sequency [OK;
Reverse; ?=Unknown
Useq
P/PHASE
SEQUENCIES
Actual voltage phase sequency [OK;
Reverse; ?=Unknown
Ioϕ
P/PHASE
SEQUENCIES
Io/ Uo angle [°]
Io2ϕ
P/PHASE
SEQUENCIES
Io2/Uo angle [°]
fAdop
P/PHASE
SEQUENCIES
Adopted frequency [Hz]
E+ E/ENERGY Exported energy [MWh]
Eq+ E/ENERGY Exported reactive energy [Mvar]
E- E/ENERGY Imported energy [MWh]
Eq- E/ENERGY Imported reactive energy [Mvar]
E+.nn E/DECIMAL COUNT Decimals of exported energy [ ]
Eq.nn E/DECIMAL COUNT Decimals of reactive energy [ ]
E-.nn E/DECIMAL COUNT Decimals of imported energy [ ]
Ewrap E/DECIMAL COUNT Energy control
E+ E/E-PULSE SIZES Pulse size of exported energy [kWh]
Eq+ E/E-PULSE SIZES
Pulse size of exported reactive energy
[kvar]
E- E/E-PULSE SIZES Pulse size of imported energy [kWh]
Eq- E/E-PULSE SIZES
Pulse duration of imported reactive
energy [ms]
E+
E/E-PULSE
DURATION
Pulse duration of exported energy
[ms]
Eq+
E/E-PULSE
DURATION
Pulse duration of exported reactive
energy [ms]
E-
E/E-PULSE
DURATION
Pulse duration of imported energy
[ms]
Eq-
E/E-PULSE
DURATION
Pulse duration of imported reactive
energy [ms]
E+ E/E-pulse TEST Test the exported energy pulse [ ]
Eq+ E/E-pulse TEST Test the exported reactive energy [ ]
E- E/E-pulse TEST Test the imported energy [ ]
Eq- E/E-pulse TEST Test the imported reactive energy [ ]
IL1 I/PHASE CURRENTS Phase current IL1 [A]
IL2 I/PHASE CURRENTS Phase current IL2 [A]
IL3 I/PHASE CURRENTS Phase current IL3 [A]
IL1da I/PHASE CURRENTS 15 min average for IL1 [A]
