AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 119
ITEM DESCRIPTION PART NUMBER QTY
REFERENCE
SECTION
I
1 NUT, HEX LOCKING 7/16-14 825507-223 2 -
2 CAPSCREW, HEX GR5 7/16-14 x 2 829107-200 4 -
3 WASHER, LOCK 7/16 838507-109 4 -
4 BELT, POLY-LINK 122 LINKS DR270814 2 -
5 BELT, SERPENTINE DR62184 1 -
6 ID, COMPRESSOR E57, 24 CFM — 1 9.3
7 ID, BELT GUARD ASSEMBLY — 1 9.7
8 ID, FRAME ASSEMBLY SKID MOUNT — 1 9.4
9 ID, ENGINE AND DRIVE PARTS — 1 9.6
10 ID, ELECTRICAL SYSTEM, REMOTE — 1 9.8
11 ID, CONTROL ASSEMBLY, SKID — 1 9.10
12 ID, INSTRUMENT PANEL — 1 9.5
13 ID, FUEL TANK ASSEMBLY — 1 9.9
14
ID, DECAL AND PLATE LOCATIONS
II
—1
9.11
(3 -Part Section)
I
For a detailed breakdown of the item number assembly, refer to the section listing in this column, for this manual.
II
Not shown; refer to the section location listed under the Reference Section column.
9.2 AIR N ARC 200 SYSTEMS ASSEMBLIES
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
