AIR N ARC 200
®
ALL-IN-ONE POWER SYSTEM
®
APPENDIX A: ADDITIONAL INFORMATION
090019-OP_r0 PAGE - 151
A.4 AIR TOOL AIR CONSUMPTION CHART (CONTINUED)
TOOL AIR REQUIRED CFM @ 90 PSI
60 Ib Pavement Breaker 48 SCFM
90 Ib Pavement Breaker 68 - 85 SCFM
4" Piercing Tool 60 SCFM
60 Ib 1650 BPM Rock Drill 95 SCFM
50 Ib 1800 BPM Rock Drill 123 SCFM
Chipping Hammer 26 - 33 SCFM
A.5 AIR N ARC 200 SERIES ALL-IN-ONE POWER SYSTEM AVAILABLE OPTIONS LIST
KEY
NO.
OPTION ITEM DESCRIPTION PART ORDER
NUMBER
QTY
1 REMOTE PANEL MOUNT This bracket is used for remote panel installation
to space panel off from truck body
A16738P 1
3 COLD WEATHER OPTION
KIT
This kit (factory install) extends cold weather
temperature operation range from 0°F to -40°F
(-18° to -40°C)
032793 1
4 BATTERY BOOST
CABLES
These cables are 25 feet in length, with quik-
connect ends
MA269938 1 set
5 30 GALLON REMOTE AIR
TANK ASSEMBLY
This remote-mounted air option allows for an
additional capacity for air storage, in addition to
the standard four gallon air tank on the machine.
OA49645 1
6 DUAL 14 GALLON (28
GALLON TOTAL) AIR
TANK ASSEMBLY
This remote-mounted air option allows for an
additional capacity for air storage, in addition to
the standard four gallon air tank on the machine.
032708 1
7 SINGLE 14 GALLON AIR
TANK ASSEMBLY
This remote-mounted air option allows for an
additional capacity for air storage, in addition to
the standard four gallon air tank on the machine.
032707 1
Continued on next page
