APPENDIX A: ADDITIONAL INFORMATION AIR N ARC 200
®
ALL-IN-ONE POWER SYSTEM
®
PAGE - 148 090019-OP_r0
A.2 EXTENSION CORD CHART
CONTINUOUS LOAD
(use either Amps or Watts below)
MINIMUM GAUGE (AWG)
AMPS @120 volts @240 volts 0-50 feet 50-100 feet 100-150 f
2 240 480 22 20 18
3 360 720 22 18 16
4 480 960 20 16 16
5 600 1200 18 16 14
6 720 1440 18 16 14
8 960 1920 16 14 12
10 1200 2400 16 12 12
12 1440 2880 16 12 10
14 1680 3660 14 12 10
16 1920 3840 14 10 10
18 2160 4320 14 10 8
20 2400 4800 12 10 8
22 2640 5280 12 10 8
25 3000 6000 12 10 6
30 3600 7200 10 8 6
35 4200 8400 10 8 4
40 4800 9600 8 6 2
50 6000 12000 6 4 2
60 7200 14400 4 2
