AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 121
9.3 COMPRESSOR AND PARTS ASSEMBLY
ITEM DESCRIPTION PART NUMBER QTY
1 COMPRESSOR, AIR, 24 CFM (E57) CM37293PBK 1
2 VALVE, POP-OFF VALVE, 70 PSI CO62609 1
3 DECAL, COMPRESSOR LOGO, ROUND DL269684 1
4 TEE, BRANCH COMP 1/8MNPT x 1/4 COMP 90 DEG . FI46707 1
5 ELBOW, COMP 1/8MNPT x 1/4 COMP 90 DEG. FI64915 1
6 ADAPTER, 90 DEG. ELBOW, 1" MPT x 3/4" SWIVEL HY83904 1
7 OIL, HYD ISO68 SE99966 2.0 QTS
8 TUBE, TIE-IN TU270817 1
9 TUBE, COMPR TO BASE TU270818 1
10 PLUG, DRAIN 1/4” NPT - 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
