AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 123
9.4 FRAME
ITEM DESCRIPTION PART NUMBER QTY
1 SCREW, SER WASH 3/8-16 x 1 829706-100 8
2 PLATFORM, 200 A1270312 2
3 MOUNT SKID A16581P 4
4 GROMMET, BLACK RUBBER, 1.75 ID PR33078 1
5 GROMMET, BLACK RUBBER, 2.25 ID PR52720 1
6 GROMMET, BLACK RUBBER, 2.25 ID PR74492 3
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
