AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 129
9.6 ENGINE AND DRIVE PARTS
ITEM DESCRIPTION PART NUMBER QTY
1 SCREW, SHEET METAL PHIL. #8 x 1 LG. 265590 1
2 CLAMP, LOOM #010 5/8" 268503 1
3 KEY, SQUARE 1/4 x 1/4 x 3 821104-300 1
4 CAPSCREW, HEX GR5 1/4-20 x 1 1/4 829104-125 5
5 CAPSCREW, HEX GR5 3/8-16 x 1.50 829106-150 1
6 CAPSCREW, HEX GR5 3/8-16 x 1.75 829106-175 3
7 WASHER, LOCK 1/4 838504-062 5
8 WASHER, LOCK 3/8 838506-094 4
9 OIL, MOTOR 10W30, 2.5 QT 844300-001 1
10 SHEAVE, SERPENTINE, 8 GROOVE A15891Z 1
11 SHEAVE, 2 GROOVE, 5.75 DOUBLE A, ZINC DR76765Z 1
12 BUSHING, SDS, QD, 1 1/8 DIA. DR85785Z 1
13 BUSHING, L, QD, 1 1/8 DIA., 2 BOLT DR92958Z 1
14 HOSE, DRAIN 3/8 x 12"LG 3/8NPT EN22698 1
15 ENGINE, GAS KOHLER 25HP EFI EN270784 1
16 ELBOW, 90 DEG., EXHAUST EN43384 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
