AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 133
9.8 ELECTRICAL SYSTEM
ITEM DESCRIPTION PART NUMBER QTY
1 WASHER, NYLON FLAT 1/4 262704 4
2 WASHER, NYLON 5/16-18 262943 4
3 SCREW, TRUSS HD 5/16-18 x 3/4 SS 262945 4
4 SCREW, TRUSS HD 1/4-20 x 3/4 262953 4
5 KEY, SQUARE 3/16 x 3/16 x 1.5 821103-150 1
6 NUT, HEX 1/2-13 825208-448 1
7 CAPSCREW, HEX GR5 1/4-20 x 1 1/4 829104-125 3
8 CAPSCREW, HEX GR5 1/2-13 x 1 829108-100 1
9 CAPSCREW, HEX GR5 1/2-13 x 1.75 829108-175 1
10 CAPSCREW, HEX GR8 5/16-18 x 7 829405-700 2
11 SCREW, SER WASH 5/16-18 x 0.75 829705-075 10
12 SCREW, SER WASH 5/16-18 x 1 829705-100 6
13 SCREW, SER WASH 5/16-18 x 1.25 829705-125 2
14 WASHER, FLAT 5/16 838205-071 4
15 WASHER, FLAT 1/2 838208-112 2
16 WASHER, LOCK 1/4 838504-062 3
17 WASHER, LOCK 1/2 838508-125 2
18 PANEL,SHIELD FACEPLATE A10592P 1
19 COVER, BATTERY LID A12524P 1
20 SUPPORT, BATTERY TRAY A12634P 1
21 FACEPLATE, COVER BLANK A12942P 1
22 SHIELD, CENTER ENCLOSURE A13426P 1
23 MOUNT, REAR GENERATOR A15865P 1
24 SHEAVE, SERPENTINE, 8 GROOVE A15891Z 1
25 MOUNT, BATTERY INDUSTRIAL, PRO A16270P 1
26 MOUNT BATTERY LID A19244P 1
27 BUSHING, SDS, QD, 7/8 DIA. DR41395Z 1
28 HARNESS, WIRE WELDER EP269873 1
Continued on page 135
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
