AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 137
9.9 FUEL TANK ASSEMBLY
ITEM DESCRIPTION PART NUMBER QTY
1 PLUG, SAE O-RING HOLLOW HEX #10 268081-007 1
2 TUBE, FUEL PICK-UP 269358 1
3 VALVE, ROLLOVER FUEL VENT 1/2 NPT 270956 1
4 PLUG, PIPE 1/4 807800-010 1
5 FUEL TANK, 11 GAL. A1270787 1
6 SENDER UNIT, FUEL LEVEL, 14 LG CO85672 1
7 HARNESS, FUEL SENDER EXTENSION, LONG EP270788-2 1
8 CLAMP, HOSE, T-BOLT STYLE, 13mm SS FA38355 2
9 CAP, UNLEADED GAS, VENTED HA270038 1
10 CAP, VINYL, STRETCH, 1/4 DIA PR62720 1
11 FILTER, INLINE FUEL 1/4-5/16" RC81465 1
12 HOSE, FUEL 1/4" X 3" LG. SAE 30R9 TU269439 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
