AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 139
9.10 CONTROL ASSEMBLY
ITEM DESCRIPTION PART NUMBER QTY
1 SWITCH, PRESSURE N.C. 10 PSI 260818 1
2 ELBOW, 1/4T x 1/8P PUSH-ON 261309 1
3
I
ELBOW, 90 DEG. PUSH-ON 1/4T x 1/4P
261310
2
4
II
CONNECTOR, 1/4P x 1/4T 261317 1
5 VALVE, PILOT VALVE, 150-175 PSI CO67609 1
6 TEE, MALE STREET 1/8 x 1/8 x 1/8 FI31152 1
7 PIPE BRASS, BULKHEAD 1/4 NPT FI45068 2
8 TUBING, 1/4 DIA. NYLON, 230 PSI x 3.5 FT. TU95945 1
AA - Connect together with tube.
I
To accumulator tank - provided by others.
II
To compressor.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
