VAT 653 Series User Manual

Series 65
TROUBLE SHOOTING
963283EA Edition 2019-05-03 103/
129
• Achsen vertauscht
• Encoder nicht angeschlossen
1 5 Motion controller: Target position can’t be
reached
• 1)
• Current settings
1 6 Motion controller: Position minimal
conductance cannot be reached
• 1)
• Check Plate and Seal ring
• Check Parameter “Isolation Position Enter
[r]”
1 7 Motion controller: Position to push back
the Differential Plate cannot be reached
• 1)
• Check Different Plate
• Check Parameter “Differential Plate Push
Back Position [r]”
1 8 Motion controller: Minimal isolation
position cannot be reached
• 1)
• Check Plate and Seal ring
•
Check Parameter “Isolation Position [r]”
2 0 Break slippery detected Replace actuator
3 0 SFV: Motion controller failure in master-
slave communication
Contact vat support
4 0 Compressed air error Check compressed air
4 2 Power supply, low voltage detected Check if power supply is ok and is able to deliver
needed power
9 6 SFV: Position deviation axis1 to axis2 at
homing procedure
• O-Ring sticking
• 1)
9 7 SFV: Position deviation axis1 to axis2 at
operating
1)
9
8
Position error
during closing procedure
1)
9
9
Position error at operating
1)
2 0 0 Valve configuration error, not possible to
operate the valve with these configuration
Contact VAT support
7 7 7 Do not operating mode active
1) Mechanical movement problem:
• Check for differential pressure
• Remove foreign object in movement area
• Eliminate tight movement
• Repair mechanical failure
If you need any further information, please contact one of our service centers. You will find the
addresses on our website: www.vatvalve.com.
