SPARE PARTS Series
124/129
Edition 2019-05-03 963283EA
12 Spare parts
NOTICE
Non-original spare parts
Non-original spare parts may cause damage to the product.
Use original spare parts from VAT only.
Please specify the fabrication number of the product when you place an order for
spare parts; see chapter: «Identification of product». This is to ensure that the
appropriate spare parts are supplied.
•
VAT makes a difference between spare parts that may be replaced by the
customer and those that need to be replaced by the VAT service staff.
•
The following table(s) contain spare parts that may be replaced by the customer. If
you need any other spare parts, please contact one of our service centers. You will
find the addresses on our website www.vatvalve.com.
12.1 Drawing
1 Plate seal 6 Integrated controller
2 Body seal 7 Rotary feedthrough seals
3 Shaft feedthroug seals 8 Pendulum plate
4 Bonnet seal 9 Sealing ring
5 Actuator
1 2 3 4
5
9 8
7
6
