VAT 653 Series User Manual

Series 65 INSTALLATION
963283EA Edition 2019-05-03 83/
129
Setup function
Command Acknowledgement
Description
PRESSURE
CONTROLLER
CONFIGURATION
Set
s:02abbc
configure parameter: set parameter
bb of pressure controller a to value c
s:02
Get
i:02abb
get value c of parameter bb of
pressure controller a
i:02abbc
a
Pressure controller:
A = Adaptive downstream pressure controller
B = Fixed 1 pressure controller (downstream or upstream)
C = Fixed 2 pressure controller (downstream or upstream)
D = Soft pump pressure controller
bb
Parameter number
(see table below)
c
Parameter value, depends on parameter number a floating-
point type or a integral type value, max length = 20 characters
floating-point type
format: x.y or x
Maximum length of expression: 12
Examples: 3455.1505, 21154.0 or 318
integer type
format: x
Maximum length of expression: 12
Examples: 9785, 4565, 1
For details (commands etc.), see the next tables.
4.11.4.1 Overview pressure controller
Parameter
Parameter
number (bb)
Pressure controller
(a)
A
Adaptive
B
Fixed
1
C
Fixed
2
D
Soft pump
SENSOR DELAY 00

– – –
RAMP TIME 01
   
RAMP MODE 02
   
CONTROL DIRECTION 03 –
 
–
P-GAIN (for A = GAIN
FACTOR)
04
   
I-GAIN 05 –
 
–
 Existent for this pressure controller / – Not used for this pressure controller
