VAT 653 Series User Manual

Series 65 DESCRIPTION OF PRODUCT
963283EA Edition 2019-05-03 9/
129
DN 100
4"
(65340 - ....)
DN 160
6"
(65344 - ....)
DN 200
8"
(65346 - ....)
DN 250
10"
(65348 - ....)
Position resolution / position control
capability
58000 steps
(full stroke)
Closing time throttling only (full stroke) 0.7 s typ.
0.4 s typ.
0.8 s typ.
0.
45
s typ.
0.9 s typ.
0.5 s typ.
0.9 s typ.
0.5 s typ.
Opening time throttling only (full stroke) 0.7 s typ.
0.4 s typ.
0.8 s typ.
0.45 s typ.
0.9 s typ.
0.5 s typ.
0.9 s typ.
0.5 s typ.
Closing time throttling & isolation (full stroke) 3 s typ. 3 s typ. 3 s typ. 3 s typ.
Opening time throttling & isolation (full
stroke)
4 s typ. 4 s typ. 4 s typ. 4 s typ.
4)
Refer to chapter «Schematics» for details.
5)
PFO = Power Failure Option. Refer to chapter «Behavior in case of power failure» for details.
