3. Before the Installation
36 Green X / X18 (Model: PHT-75CHS) Installation Manual
Part
No.
Items Specification Figure QTY Comments Confirmed
Round Base
Cap
White Silicone
1 Base Option Yes □ No □
18 Left Blank Intentionally
19
Flat Head
Screw
M4 x 16 4
For Rear
Cover Vertical
Rear
Yes □ No □
20 Cable Tie n/a 10 n/a Yes □ No □
21
Frame
Grabber
System
Optic Cable 1
One additional
fiber optic
cable is
required when
SC type is
installed
Yes □ No □
FTG Card
(or)
LEG Card
1 n/a Yes □ No □
22
Column
Bracket
n/a
1 n/a Yes □ No □
Model Scan
Jig
n/a
1
For the 3D
MODEL Scan
model
Yes □ No □
Protractor n/a 1 n/a Yes □ No □
23 Wrench Bolt
M10 x 25
w/ Spring and
Flat Washers
6 Base Option Yes □ No □
24 Wrench Bolt M8 x 35 2 Base Option Yes □ No □
25
Wrench Bolt M8 x 20
4 n/a Yes □ No □
C E Washer
1 Sems
n/a 4 n/a Yes □ No □
26 Truss Bolt M4 x16 3 Base Option Yes □ No □
