3. Before the Installation
Green X / X18
(Model: PHT-75CHS) Installation Manual 37
English
Part
No.
Items Specification Figure QTY Comments Confirmed
27 Truss Bolt M4 x10
13 n/a Yes No
28
Flat Head
Screw
M3 x 6
2
CEPH Option
Yes No
CEPH Arm
Cover
n/a
1 Yes No
29
Wrench Bolt
(2 Sems)
M8 x 15
4 n/a Yes No
30 Set Screw M10 x 20
4 n/a Yes No
31
Wall Plate n/a
1 n/a Yes No
Terminal Block
3 Pole
n/a
1 n/a Yes No
32
Wall mount
cap
Silicone
12 n/a Yes No
33
UP / DOWN
Switch
n/a
1
Optional
Yes No
UP / DOWN
Switch Holder
n/a
1 Yes No
Double-Sided
Sticker
n/a
1 Yes No
Truss Bolt M4 x 10
2 Yes No
34
Wood bolt M8 x 60
4 For Wood Wall Yes No
Spring Washer M8
4 n/a Yes No
Flat Washer M8
4 n/a Yes No
Flat Anchor
Bolt
M8 x 30
4 n/a Yes No
Hex Bolt M8 x 15
4 n/a Yes No
