3. Before the Installation
38 Green X / X18 (Model: PHT-75CHS) Installation Manual
Part
No.
Items Specification Figure QTY Comments Confirmed
Wood Screw M12 x 70
2 For Wood Wall Yes □ No □
Anchor Bolt
5/16 x 60 w/
Spring and
Flat Washers
6 For Concrete Yes □ No □
35
Wrench Bolt M8 x 25
2 n/a Yes □ No □
Nut M8
2 n/a Yes □ No □
36
Wall Bracket
Rear
n/a 1 n/a Yes □ No □
Wood Wall
Bracket
n/a
For the U.S,
only
Yes □ No □
Vertical Cap n/a 1 For PANO only Yes □ No □
3.5.2.2 Additional Parts
Part No.37 and 38 are separately stored from other accessories as illustrated below:
Part
No.
Items Specification Figure QTY Comments Confirmed
37
Lower Column
Cover
n/a 1 n/a Yes □ No □
38
Back Column
Cover
n/a 1 n/a Yes □ No □
