5. Installing the X-ray Unit: Wall Mount Type

Green X / X18

(Model: PHT-75CHS) Installation Manual 75

English

5. Place the spirit level inside the Vertical Frame as indicated below.

6. Fasten each screw as indicated below to secure the column.
