Vatech PaX-i3D Smart

Pax-i3D Smart(PHT-30LFO) Installation Manual
138
10 Technical Specications
Mechanical Specications
ItemW Description
Weight
without CEPH unit
Without Base 167 kg (368.2 lbs)
with Base 220 kg (485 lbs)
with CEPH unit (scan type)
Without Base 202 kg (445.3 lbs)
with Base 255 kg (562.2 lbs)
Total Height Max. 2336 mm (92 inch)
Vertical Column Movement
Max. 700 mm (Max. 27.6 inch)
Dimension
(Length x Width
x Height)
without CEPH unit
1113 (L) x 1389(W) x 2336 (H) mm
43.8(L) x 54.7(W) x 92(H) inch
with CEPH unit (scan type)
1882 (L) x 1400 (W) x 2336 (H) mm
74.1(L) x 55.1(W) x 92(H) inch
with CEPH unit (oneshot
type)
1882 (L) x 1400 (W) x 2336 (H) mm
74.1(L) x 55.1(W) x 92(H) inch
Type of installation Base stand / Wall mount
