Pax-i3D Smart(PHT-30LFO) Installation Manual
148
Appendix
C. Limiting the Column Height
This section explains how to limit the column height within permissible range.
1.
Measure the ceiling height in the X-Ray shield room :
H
ceiling
Removing the column covers
2.
Remove the moving column back cases as shown
in the gure
3.
Remove the column rear-top cover as shown
in the gure.
