Vatech PaX-i3D Smart Installation Manual

Pax-i3D Smart(PHT-30LFO) Installation Manual
150
Appendix
Adjusting the screw height
We know the screw height is 236mm from the previous example. So we will move the screw from the
default (current) position to new one.
1.
Loosen the bolt halfway
(important!).
Do not unscrew completely the bolt or it could drop into the column, causing
a big trouble to retrieve it out.
