Pax-i3D Smart(PHT-30LFO) Installation Manual
34
3 Before Installing the System
1.
Move the main box to a convenient place as close as possible to the installation location
2.
Separate the top cover after removing the
strapping bands.
3.
Lift up a small distance and remove the side
covers.
TOP
Bottom
A
B
C
D
E
A: PC system (Optional)
B: PE foam
C: PE foam
D: Accessory and part box1
E: Accessory and part box2
