Vatech PaX-i3D Smart

Pax-i3D Smart(PHT-30LFO) Installation Manual
39
3 Before Installing the System
Box No. 3: Cephalometric unit (Optional)
Component Size(mm/inch) Weight(kg/lbs)
Cephalometric unit
1605(L) x 875(W) x 900(H) /
63.2"(L) x 34.4"(W) x 35.4"(H)
50/110
875mm/34.4"
1605mm/63.2"
900mm/35.4"
Removing the cover
1.
Open the box cover, starting with the top cover.
